Make the Connection. Deliver your Message. Collaborate with Confidence.

Wireless Presentation & Collaboration Solution
Extensive Content


Cross-Platform Support
From the laptops, tablets, and smartphones your team uses to those brought in by guests, a wide array of different devices enters your conference room in any given week. To ensure compatibility with just about everything, NovoEnterprise boasts cross-platform support with Windows, Mac, Android, iOS, and Google devices.
4K Ultra HD


AirPlay & Google Cast Support
NovoEnterprise fully supports Apple AirPlay and Google Cast, enabling quick and simple screen mirroring and content streaming from a wide number of today’s most popular laptop, tablet, and smartphone devices.
Extensive Content


Quad-View &
Dynamic Screen Layouts
Perfect for comparing and collaborating, NovoEnterprise can display/mirror up to four different screen sources simultaneously. This means AirPlay, Google Cast, and regular PC mirroring can all run concurrently, side-by-side in default layouts or dynamically rearranged to match the user’s preference.
Extensive Content


Intuitive On-Screen Operations
Managing 64 simultaneous users, rearranging mirror windows, and placing on-screen annotations might sound difficult in concept, but NovoEnterprise makes executing these tasks easy and intuitive thanks to its user-friendly, touch-capable on-screen interface.
4K Ultra HD


Versatile HDMI Input
In addition to its robust wireless connectivity capabilities, NovoEnterprise features an HDMI input port that facilitates simple and reliable hardware connections. While most users will use this port to establish a hardwired connection between their computer and their NovoEnterprise unit, it can also be used to connect document cameras, Blu-ray players, and other HDMI-capable devices.
Extensive Content


Centralized Management
As with all of the products in the NovoConnect family, NovoEnterprise can be remotely accessed, updated, and operated via the standalone Remote Manager application. Available for Windows and Mac, Remote Manager enables network-wide control over your entire NovoEnterprise fleet from a single computer.
  • Intuitive ease of use
  • Connect up to 64 users; 4-to-1 Split screen simultaneously on one display
  • Full Screen mirroring of multi-platform operation systems
  • Built-in dual network support (Wireless and Wired)
  • On-screen annotation mark-up and distribution
  • Built in Whiteboard capability with touch panel compatibility
  • Supports video playback with perfect synchronization up to 1080p
  • Remote management and maintenance software for ease of deployment
Series Name NovoConnect
Product Name NovoEnterprise
Model Name NE3000US
Hardware WiFi 802.11 ac/b/g/n
2.4GHz/5GHz
Antenna External 2T2R
up to 300 Mbps
LAN 10/100/1000 Mbps
Display Resolution up to WUXGA (1920x1200)
Output HDMI out x 1
Audio out 3.5mm mini jack
Input HDMI in x 1
Audio in 3.5mm mini Jack x 1
USB Type A x 2
RJ45 (PoE)
MicroSD card slot x 1
DC jack Power-in
Kensington Lock
Storage Internal - 8GB (eMMC flash)
External -MicroSD card slot (up to 32GB)
Remote Control RF
Security AES-128 encryption
Ambient Temperature Operating: 32° ~ 104° F; 0° ~ 40° C ; Storage: -4° ~ 140° F; -20° C ~ 60° C
Power Input to AC Adaptor: AC 100-240V, 50/60Hz; Output from AC Adaptor: 5V/2A; Consumption: 10W
Dimension
(L x W x H)
6.5" x 4.8" x 0.8"
(165 mm x 123 mm x 21 mm)
Weight 8.82 oz (250 g)
What is in the box HDMI cable x 1,
Micro USB to USB cable x 1,
Wall Mount Kit x 1,
Remote control x 1
USB Power Adapter
Antenna x 2
AAA battery x 2
Software Video Quality FHD(1080P/60fps)
OS support Windows 7 / 8 / 10 (32 bits and 64 bits), Mac 10.7 and above,
iOS 7.0 and above, Android 4.0 and above, Chromebook 37+
Cross-Platform Mirroring V
Air Play V
Google Cast V
MiraCast
4-to-1 Screen (Quad screen) V
Dynamic Screen layout V
Intutitive on-screen operation V
Simultaneous Connections up to 64
Software Edition Corporate
Moderator Preview (Edu only) V
Screen Annotation tool V
File / URL sharing V
Voting / Polling V
AirNote V
Whiteboard V
Classroom management (attendance, lock student tablets, etc.) V
HD Video and You Tube streaming V
Device Management Firmware upgrade FREE
Software upgrade FREE
Remote Manager FREE
Type Title Version Type Size   Download
Brochures
  NovoConnect Series Brochure 10/2017 pdf 12.27 MB
  Vivitek Catalog 2019 06/2019 pdf 21.59 MB
Guides
  NovoEnterprise Quick Start Guide 08/17 pdf 2.87 MB
  NovoScreennote User Guide 12/2017 pdf 3.57 MB
AppNotes
  How to Enable and Disable Audio (PC/Mac) pdf 0.51 MB
  Moderator Credentials - Configuration and Usage pdf 0.81 MB
  Reset Setting Protection Password pdf 0.55 MB
  Stream Video from Your Computer pdf 0.57 MB
  Manual Firmware Upgrade Process pdf 0.50 MB
ReleaseNote
  NovoConnect Series Desktop Streamer ReleaseNote V3.0.2 11/2017 pdf 0.58 MB
  NovoConnect Series Remote Manager ReleaseNote V3.0.0 1/2018 pdf 0.51 MB
Type Title Version Type Size   Download
NovoConnect Software/Mobile App
  Windows 7 and above V4.2.0 exe 59.86 MB
  Windows silent installer package (exe) V4.2.0 exe 59.84 MB
  Windows silent installer package (msi) V4.2.0 msi 64.03 MB
  Mac OS 10.7 and above V4.2.0 zip 56.67 MB
  Linux installer package (deb) V 4.2.1 deb 92.38 MB
  Chromebook (V.37 and above) V3.2.3 Ext. URL N/A
  iOS mobile App V4.2.0 Ext. URL N/A
  Android mobile App V4.2.0 Ext. URL N/A
Screen Extension
  Windows 10 V1.0.2 exe 0.74 MB
  Windows 10 (Silent installer) V1.0.2 exe 0.74 MB
  Windows 10 (MSI version – please install as admin) V1.0.2 msi 3.53 MB
Remote Manager
  Windows 7 and above V3.1.5 exe 14.13 MB
  Windows silent installer package (exe) V3.1.5 exe 14.12 MB
  Remote Manager DB Server for Windows V1.1.0 exe 10.21 MB
NovoScreenote
  Windows 7 and above V2.1 exe 116.32 MB
