| Display | Type/Technology | Backlit D-LED (VA Panel) | |
| Panel Size | 65” | ||
| Brightness (Typ) | 400cd/m2 | ||
| Contrast Ratio (Typ) | 4,000:1 | ||
| Native Resolution | 4K Ultra-HD (3840 x 2160) | ||
| Viewing Angle (H/V) | 178o/178o | ||
| Aspect Ratio | 16:9 | ||
| Response Time (MS) | 8ms (Typ) | ||
| Refresh Rate (Hz) | 60Hz | ||
| Estimated Life Time (Typ) | 30,000 hours (Min) | ||
| Display Color (Bit) | 1.07 billion (10-bit) | ||
| Installation Orientation | Landscape | ||
| Daily Operation (Hours/Days) | 16/7 | ||
| Interactivity | Technology | Infrared Touch | |
| Touch Points | Writing | 10 Point (Standard) | |
| Touch | 50 Point (Standard) | ||
| Accuracy | Finger | ±1mm (Over 90% area) | |
| Passive Pen | ±1mm (Over 90% area) | ||
| Response Time | <2.5ms | ||
| Touch Resolution | 32,768 x 32,768 | ||
| Surface Protection | 3mm Anti-Glare Thick Toughened Glass (Level 7H on Mohs Scale of Mineral Hardness) | ||
| Touch Tools | Finger, Stylus, Glove, Opaque Objects | ||
| Anti-Palm | Supported | ||
| Operating System | System Version | Android™ v13.0 | |
| CPU | Qcta-Core High-Performance ARM®CPU | ||
| GPU | Mali™ G610 MP4 | ||
| RAM | 8GB DDR5 | ||
| Internal Storage | 64GB (eMMC Flash) (About 25GB User Availability) | ||
| Connectivity | Input | Display | HDMI v2.0 (x3) Side HDMI v2.0 (x1) Front DP v1.4&v2.3 (x1) Bottom USB-C (x1) Side |
| Audio | Mic(3.5mm)(x1) | ||
| Output | Display | HDMI-Out v2.0 (x1) (up to 4K@60Hz) USB-C (x1) (up to 4K@60Hz) | |
| Audio | Line-Out (3.5mm) (x1), SPDIF-Out (x1) | ||
| Internet | LAN (RJ45) (10/100/1000 Mbps) (x2) | ||
| Control | RS232-In (x1) | ||
| Wireless | WiFi | IEEE802.11ax (2.4GHz/5GHz) | |
| Bluetooth | BT 5.2 | ||
| I/R Receiver | Front (x1) (±25° Angle, >8m Distance) | ||
| USB-A | Front | USB 3.0 (x2) | |
| Side | USB 3.0 (x2) | ||
| Bottom | USB 2.0 (x1, For system upgrade) | ||
| USB-B | Side | USB Type B (x1) (For HDMI Input Touch Port) | |
| Side | USB Type B (x1) (For DisplayPort Touch Port) | ||
| USB-C | Front | USB-C in(x1) (up to PD 20V/5A charging, display input) | |
| Bottom | USB-C in(x1) (up to PD 5V/3A charging, display output) USB-C Out (x1) | ||
| Expansion | OPS Slot | Standard Intel 80pin OPS | |
| Audio | Speakers | 2x8W + 2x18W (2.2CH, Top-mounted) | |
| Microphones | 8-microphone array (Pickup radius: 8M) | ||
| Power | Power Supply (Internal) | AC 100 - 240V, 50/60Hz (4.0A) | |
| Consumption | ≤195W | ||
| Standby Mode | ≤0.5W (Standby) | ||
| Physical Characteristics | VESA Mounting (FPMPMI) | 600 x 400mm | |
| M8x25(mm) | |||
| Dimension (L x H x D) | 1,484.5 x 909 x 86 mm (58.4” x 35.8" x 3.4") | ||
| Weight | 38.7kg (85lbs) | ||
| Color | Gray | ||
| Accessories | Standard | AC Power Cord, Stylus (x2), Remote Control (W/Batteries), Wall Mount Kit, HDMI Cable(3M), Touch Cable(3M) Documentation Kit | |
| Optional | Windows OPS Module – Standard 80pin | ||
