BK652i
BK Series, Wireless Collaboration, Digital Whiteboard, Digital Signage, Collaborative Touch Panel
The NovoTouch BK series is a 4K-UHD collaborative touch display solution that is perfect for education, but also for business meetings, available in 65”, 75”, and 86” display sizes. NovoConnect Wireless Collaboration allows any participant to effortlessly share their device screen on the NovoTouch BK display, while the digital whiteboard function enhances the classroom experience with flawless touch annotation for truly interactive sessions. The built-in digital signage solution is easy to set up and manage via the optional NovoDS Cloud service or included NovoDS Studio software
  •   NovoConnect Wireless Collaboration
    • The BK series has built-in NovoConnect Lite wireless presentation and collaborative tools for cable-free and hassle-free presenting in the classroom or in the office.
    • Up to 8 participants can be connected and 2 can share their screen, each in 1080p resolution.
    • World Class Security- AES-256 Encryption, Password Protected, Dual Network Environment, ISO 27001 Certified.
  • Digital Whiteboard
    • The BK series supports 20-point interactive touch capability. The digital whiteboard enables flawless annotation, highlighting and screen capture for easy sharing.
  • NovoDS Digital Signage
    • The built-in digital signage solution is easy to set up and manage via the optional NovoDS Cloud service or included NovoDS Studio software.
    • The user can toggle between the Wireless Collaboration and Digital Signage function to maximise the use of the display at any time.
  • Google Play enabled
    • Easy access to any Google Play app allows for even more flexible use and optimized working and teaching in any session.
  • 4K UHD Resolution and rich connectivity
    • The BK series 65” / 75” / 86” display size with 4K Ultra-HD (3, 840 x 2, 160) resolution to deliver outstanding details and stunning visuals. The multiple interfaces, such as USB Type-C, HDMI and USB2.0/3.0 allow easy connection to various devices.
  • Backlit D-LED Technology
    • Backlit D-LED (IPS panel) with Optical Bonding technology delivers brighter pictures, flawless colors, richer textures, and extra wide viewing angles (178?/ 178?). The result is incredibly sharp and crisp images.
  • Eye Protection Technology
    • The BK series is TÜV Rheinland Certified to ensure the best eye projection with low Blue Light & Flicker Free feature for the best viewing experience.
Display Panel Size 65”
Type/Technology Backlit D-LED (IPS- Panel)
Brightness (Typ) 400 cd/m2
Contrast Ratio (Typ) 5000:1
Native Resolution 4K Ultra-HD (3840 x 2160)
Viewing Angle (H/V) 178° / 178°
Aspect Ratio 16:9
Refresh Rate (Hz) 60Hz
Estimated Life Time (Typ) 50,000 hours (Min)
Display Color (Bit) 1.07 billion (10-bit)
Landscape
Daily Operation (Hours/Days) 16/7
Interactivity Technology Infrared Touch
Touch Points Annotation 10 Points
Touch 20 Points
Accuracy Passive Pen ±1mm (Over 90% area)
Touch ±1mm (Over 90% area)
Touch Resolution 32, 768 x 32, 768
Surface Protection 3mm Thick Toughened Glass (Level 7H on Mohs Scale of Mineral Hardness)
Touch Tools Finger, Stylus, Glove, Opaque Objects
Operating System System Version Android™ v13.0
Internal Storage 32GB (eMMC Flash) (About 25GB User Availability)
Connectivity Input Display Side: HDMI v2.0 x3, Front: HDMI v2.0 x1
Audio Line-Out (3.5mm) x1, SPDIF-Out x1
Output Display HDMI-Out v2.0 x1 (up to 4K@60Hz)
Audio Line-Out (3.5mm) x1, SPDIF-Out x1
Internet LAN (RJ45) x2
Control RS232-In x1
Wireless WiFi 6, IEEE802.11ax (2.4GHz/5GHz), BT 5.2
USB Port Front: USB-A 3.0 x2, USB-B x1 (For Touch) USB-C 3.1 (15W power) x1 Side: USB-A 3.0 x2, USB-B x1 (For Touch), USB-A 2.0 x1,
Default Apps Collaboration Screen mirroring (NovoConnect Lite version), Digital Whiteboard, WPS Office, Google Play, NT Live Receiver, Finder
Digital Signage NovoDS App
Expansion Windows (OPS ) Intel Standard 80 Pin OPS- Optional
Audio Speakers 18W x2 (Stereo)
Device Management PC / Cloud Based Free Software- Remote Manager / Remote Manager Cloud
Power Power Supply (Internal) AC 100 - 240V, 50/60Hz (4.5A)
Consumption ?360W
Standby Mode <0.5W (Standby)
Physical Characteristics Dimension (L x H x D) mm 1484.5x90x908
Weight 39kg
VESA Mounting (FPMPMI) 4 – M8 × 25mm, 600 x 400mm
Color Silver
Accessories Standard AC Power Cord, Stylus (x2), Remote Control (W/Batteries), Wall Mount Kit, HDMI Cable (3M), Touch Cable (3M), WiFi Antenna(x3), Documentation Kit
Optional LauncherPlus, Windows OPS Module – Standard 80pin
Warranty Standard 3-Year warranty on the panel
Education 5-Year warranty on the panel, where end customer is a school, university, or training centre. Education product registration required within 180 days of purchase for extended warranty to be valid.
